Precise Durable Cigarette Filter Machine Intermediate Speed ZL23 With Fibre 250m/min

Name: Precise Durable Cigarette Filter Machine Intermediate Speed ZL23 With Fibre 250mmin
Brand: Upperbond
Price: 1 USD

Brand Name : Upperbond

Place of Origin : China

MOQ : 1 Set

Payment Terms : T/T, L/C

Supply Ability : 200 sets per year

Delivery Time : 30Works Dates

Packaging Details : Wooden Case

Price : Negotiation

Color : White

Capacity : 250m/min

Brand : Upperbond

Circle of filter rod : 24.0～24.5mm±0.20

Unit power : 22KW

Model Number : ZL23

Contact Now

Precise Durable Cigarette Filter Machine Intermediate Speed ZL23 With Fibre 250m/min

ZL23 set of fiber filter rod forming machine consists of YL13 loose gluing machine andYL23 filter rod forming machine. It takes cellulose acetate tows or polypropylene tows as raw material, after air loosing,thread loosing,gluing,involution,sideseal,forming and cutting, formed equilong filter tipping rod which meet the high-speed adapter request.

The machine can also use acetate tow and C tow. Opium pipe uses unitary and hot melt adhesive side sealing, making it easy for adjustment and operation, and reliable for splicing.The rod cutting blade applied with automatically cut feeding and automatically sharpen makes the filter rod notch smooth and flattening.

Opener applied with three-level air opening,two-level thread roller opening to completely stretch,loose,spread and gluing uniformity, and the forming machine take high-precision spiral bevel gear and paralleling short shaft driving, single tool rod cutting, to make sure small error of filter rod length.

Parameters:

Technical parameter
Product capability	250m/min(vinegar fiber) 160m/min(C fiber)
Length of filter rod :	80-144mm±0.5
Circle of filter rod:	24.0～24.5mm±0.20
Devilation from circular form:	≤0.35mm
Unit power:	22KW
Compressedair:	flow≥1.5m3/min, Kpa≥0.5MPa
Unit weight:	3500Kg
